Frameset
Frame | Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR |
Fork | SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel |
Wheels
Front Hub | Formula DC-20, alloy, 6-bolt, 5x100mm QR |
Rear Hub | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR |
Rims | Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
Tires | Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20'' |
Drivetrain
Shifters | Shimano Altus M315, 8 speed |
Front Derailleur | Shimano Altus M315, 34.9mm clamp, top swing, dual pull |
Rear Derailleur | Shimano Altus M310 |
Crankset | Shimano M315, 36/22, 175mm length |
Bottom Bracket | Sealed cartridge, 73mm |
Cassette | Shimano HG200, 12-32, 8 speed |
Chain | KMC Z8.3, 8 speed |
Components
Saddle | Bontrager Arvada, steel rails, 138mm width |
Seatpost | Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
Handlebar | Bontrager alloy, 31.8mm, 5mm rise, 720mm width |
Stem | Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length |
Head Set | Semi-integrated, 1-1/8'' |
Brake Set | Tektro HD-M275 hydraulic disc, 160mm rotor |
Weight
Weight | M - 13.97 kg / 30.81 lbs |
Weight Limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
